Sunderland Strategic Transport Corridor

GEOTECHNICAL EXCELLENCE DELIVERED FOR MAJOR STRUCTURE IN THE NORTH EAST

Project Description

SCOPE OF WORKS 1600No. Soil Nails, 3No Trial Anchors, 114No Ground Anchors, 85m contiguous bored pile retaining wall, 65lm retaining wall founded on 750mm diameter CFA piles
EQUIPMENT X2 Excavator mounted rigs, (24T and 35T, Casagrande C6 XP-2 CLIENT Sunderland City Council
MAIN CONTRACTOR Esh Civils
TYPE OF CONTRACT Subcontract
CONSTRUCTION PERIOD August 2019-January 2021

Aarsleff Ground Engineering were appointed in July 2019 by Principle Contractor Esh Civils to deliver a geotechnical works package as part of the Sunderland Strategic Transport Corridor project on behalf of Client Sunderland City Council.

A significant number of retaining structures including 85m of contiguous bored pile retaining wall, 65lm retaining wall founded on CFA piles, a 250m long x 12m high Soil Nail wall and a large King Post Retaining wall encapsulating the existing 10m high retained wall pinned with ground anchors, were necessary to create space for the highway between the Pallion Shipyard and the upper existing highway and Tyne & Wear metro line; the latter borders the southern side of the land but at a much higher level.

With existing land falling steeply across the site, and large industrial facilities to be negotiated, retaining structures and slope stabilisation works were key to making this possible along with an historic backfilled Quarry which the old shipyard have been constructed on.

Download the case study to read more.

Download
Case Study

We were delighted to carry out these challenging geotechnical works. Delivering a contiguous bored pile wall combined with a large soil nailed retaining structure and the permanent anchors required close team work and good communication with our Client and Client’s team.

Dr. Dan Adams

Aarsleff’s senior geotechnical consultant
